Back panel I/O ports
Microphone in:The socket where a microphone is connected to the device.
Headphone outputs:Number of sockets /ports where headphones are connected.
1
DisplayPorts quantity:Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
DVI-D ports quantity:This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-D means DVI digital, which means it can only support digital, but not analog.
0
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
VGA (D-Sub) ports quantity:Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
0
PS/2 ports quantity:The number of PS/2 connectors for keyboards and mice. Its name comes from the IBM Personal System/2.
1
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
2
USB 2.0 ports quantity:Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
BIOS
System Management BIOS (SMBIOS) version:
2.7
BIOS type:The BIOS (Basic Input/Output System) initializes and tests system hardware components, and loads a bootloader or an operating system from a mass memory device. The BIOS additionally provides abstraction layer for the hardware, i.e. a consistent way for application programs and operating systems to interact with the keyboard, display, and other input/output devices. There are several types of BIOS, including the motherboard ROM BIOS, video BIOS, drive controller BIOS, network adapter BIOS, and SCSI adapter BIOS.
UEFI AMI
Expansion slots
PCI Express x16 (Gen 5.x) slots:
1
PCI Express x16 (Gen 3.x) slots:Places where PCI Express x16 (Gen 3.x) are placed inside and connected to the computer motherboard.
1
PCI Express x16 (Gen 4.x) slots:
1
PCI Express x1 (Gen 3.x) slots:
2
Features
Windows operating systems supported:Windows vesions wich can be used with the device.
Windows 10 x64, Windows 11 x64
Audio output channels:An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.
7.1 channels
Audio chip:
Realtek ALC897
Motherboard chipset:The chipset connects the microprocessor to the rest of the motherboard.
Intel Z690
Motherboard chipset family:The category of motherboard chipset e.g. Intel, AMD.
Intel
Motherboard form factor:Design of the motherboard (ATX, BTX etc).
ATX
Component for:What this product is used as a part of (component for).
PC
Graphics
HDCP:High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
Internal I/O
EPS power connector (8-pin):
Peripheral (Molex) power connectors (4-pin):White 4-pinned connector used to connect a peripheral to the power supply.
1
ATX Power connector (24-pin):
Front panel audio connector:
Number of SATA III connectors:Serial ATA (Advanced Technology Attachment) (SATA) is a computer bus interface that connects host bus adapters to mass storage devices such as hard disk drives and optical drives. SATA III (revision 3.x) interface, formally known as SATA 6Gb/s, is a third generation SATA interface running at 6.0Gb/s. The bandwidth throughput, which is supported by the interface, is up to 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface.
8
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
2
USB 2.0 connectors:The end of a cable with a USB 2.0 connector. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), in addition to the "USB 1.x Full Speed" signaling rate of 12 Mbit/s. USB 2.0 connectors are usually colored black.
2
Logistics data
Harmonized System (HS) code:
84733020
Memory
Maximum internal memory:The maximum internal memory which is available in the product.
128 GB
Memory channels:
Dual-channel
Memory slots type:A memory slot, also known as a memory socket or RAM slot, is what allows computer memory (RAM) to be inserted into the computer. Depending on the motherboard, there will usually be 2 to 4 memory slots (sometimes more on high-end motherboards). The most common types of RAM are SDRAM and DDR for desktop computers and SODIMM for laptop computers, each having various types and speeds.
DIMM
Supported memory types:Types of memory which can be used with the product.
DDR4-SDRAM
Network
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
LAN controller:
Dragon RTL8125BG
Ethernet interface type:
2.5 Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
LAN controller:
Dragon RTL8125BG
Ethernet interface type:
2.5 Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Other features
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
1 kg
Processor
Maximum number of SMP processors:
1
Compatible processor series:A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'.
Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7
Processor socket:Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
LGA 1700
Processor manufacturer:The manufacturer that produced the processor.
Intel
Rear panel I/O ports
Microphone in:The socket where a microphone is connected to the device.
Headphone outputs:Number of sockets /ports where headphones are connected.
1
DisplayPorts quantity:Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
DVI-D ports quantity:This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-D means DVI digital, which means it can only support digital, but not analog.
0
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
VGA (D-Sub) ports quantity:Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
0
PS/2 ports quantity:The number of PS/2 connectors for keyboards and mice. Its name comes from the IBM Personal System/2.
1
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
2
USB 2.0 ports quantity:Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
Storage controllers
RAID levels:RAID is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required.
0, 1, 5, 10
RAID support:The device uses RAID, which is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required.
Number of storage drives supported:
11
Supported storage drive interfaces:
M.2, SATA III
Weight & dimensions
Height:The measurement of the product from head to foot or from base to top.
70 mm
Depth:The distance from the front to the back of something.
244 mm
Width:The measurement or extent of something from side to side.
305 mm
