Design
Market positioning:
Gaming
Display
Vertical scan range:
48 - 165 Hz
Horizontal scan range:
30 - 200 kHz
Display number of colours:
16.7 million colours
Viewing angle, vertical:Maximum vertical angle at which a display can be viewed with acceptable visual performance.
178°
Viewing angle, horizontal:Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
178°
Maximum refresh rate:
165 Hz
Contrast ratio (typical):The difference in light intensity between the brightest white and the darkest black.
3000:1
Screen curvature rating:
1500R
Response time:The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)
1 ms
Display brightness (typical):
250 cd/m²
LED backlight:A backlight is a form of illumination used in liquid crystal displays (LCDs). One type of backlight is made by LEDs, which can be either white or RGB (red green blue). White LEDs are used most often in notebooks and desktop screens, and in virtually all mobile LCD screens. RGB LEDs for backlighting are found in high-end color proofing displays such as HP DreamColor LP2480zx monitor or selected HP EliteBook notebooks, as well as newer consumer grade displays such as Dell's Studio series laptops which have an optional RGB LED display.
HD type:Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
Full HD
Touchscreen:A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
Display technology:The technology used in the display e.g. plasma, LED.
LED
Native aspect ratio:The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
16:9
Display resolution:The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
1920 x 1080 pixels
Display diagonal:Size of the display for this product, measured diagonally, usually in inches.
59.9 cm (23.6")
Ergonomics
Tilt angle range:
-5 - 23°
Tilt adjustment:The tilt, which means the angle at which the device is pointing (up or down), can be changed.
Height adjustment:The part of the device that can be adjusted to change the height.
Cable lock slot type:
Kensington
Cable lock slot:Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.
Panel mounting interface:
100 x 100 mm
General
Type:Characteristics of the device.
Computer Monitors
Logistics data
Harmonized System (HS) code:
85285210
Multimedia
Built-in camera:The product has an integrated camera.
Built-in speaker(s):The device contains speaker(s) to produce sound.
Other features
Country of origin:Country where the device is made.
China
Packaging content
Quick start guide:Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
Cables included:
AC, DisplayPort, HDMI
Packaging data
Package type:The type of product package e.g. box.
Box
Package weight:Weight of the packaged product.
5.06 kg
Package height:The distance from the top to the bottom of the packaging.
188 mm
Package depth:The distance from the front to the back of the packaging.
612 mm
Package width:The distance from one side of the packaging to the other.
398 mm
Performance
Low Blue Light technology:
AMD FreeSync type:
FreeSync Premium
Ports & interfaces
HDCP:High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
Headphone out:The socket for connecting headphones to the device.
DisplayPorts quantity:Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
2
HDMI:HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
DVI port:Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
VGA (D-Sub) ports quantity:Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
0
Power
European Product Registry for Energy Labelling (EPREL) code:
390290
Energy efficiency scale:
A to G
AC input frequency:
50/60 Hz
AC input voltage:The voltage of the AC electricity that is inpitted into the product.
100 - 240 V
Power consumption (off):
0.5 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
23.34 W
Energy consumption (SDR) per 1000 hours:
22 kWh
Energy efficiency class (SDR):
F
Weight & dimensions
Weight (without stand):
2.64 kg
Height (without stand):
320 mm
Depth (without stand):
69.9 mm
Width (without stand):
537.6 mm
Weight (with stand):
3.37 kg
Height (with stand):
404 mm
Depth (with stand):
205.9 mm
Width (with stand):
537.6 mm
