Antenna
Antenna gain level (max):Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction.
7 dBi
Certificates
Compliance certificates:
CE, Federal Communications Commission (FCC), Industry Canada (IC)
Certification
Compliance certificates:
CE, Federal Communications Commission (FCC), Industry Canada (IC)
Design
Built-in display:A display which is part of the product, so you do not need to attach another display.
Display type:Type of display (screen) e.g. LCD.
LCM
Housing material:
Polycarbonate (PC)
Product type:The sub-category of the product.
Tabletop router
Features
Bluetooth:Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Number of simultaneously connected devices (max):
300
Internal memory:The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
3000 MB
Processor cores:The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
4
Processor frequency:The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time.
1500 MHz
Processor architecture:
ARM Cortex-A53
Management features
Quality of Service (QoS) support:
Web-based management:Using a website/web application to manage something.
Network
Maximum Tx power (2.4 GHz):
23 dBmW
Maximum Tx power (5 GHz):
26 dBmW
VPN server:
Identity Endpoint One-Click VPN, Teleport Zero-Configuration VPN, WireGuard, OpenVPN, L2TP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1Q
Ethernet LAN data rates:The different speed levels of the Ethernet LAN connection.
2500 Mbit/s
Ethernet LAN interface type:
2.5 Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Maximum Tx power (2.4 GHz):
23 dBmW
Maximum Tx power (5 GHz):
26 dBmW
VPN server:
Identity Endpoint One-Click VPN, Teleport Zero-Configuration VPN, WireGuard, OpenVPN, L2TP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1Q
Ethernet LAN data rates:The different speed levels of the Ethernet LAN connection.
2500 Mbit/s
Ethernet LAN interface type:
2.5 Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Operational conditions
Operating relative humidity (H-H):
5 - 95%
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-10 - 40 °C
Packaging content
Packaging data
Number of products included:The number of products that are included in the package.
1 pc(s)
Ports & interfaces
Fiber optic connector:This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.
SFP+
Compatible memory cards:Types of memory cards which can be used with this product.
MicroSD (TransFlash)
Memory card slot(s):Places where memory cards are placed inside and connected to the computer motherboard.
USB port:Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the cables, connectors and communications protocols used in a bus for connection, communication, and power supply between computers and electronic devices. USB was designed to standardize the connection of computer peripherals (including keyboards, pointing devices, digital cameras, printers, portable media players, disk drives and network adapters) to personal computers, both to communicate and to supply electric power. It has become commonplace on other devices, such as smartphones, PDAs and video game consoles. USB has effectively replaced a variety of earlier interfaces, such as serial and parallel ports, as well as separate power chargers for portable devices.
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
4
Power
Power over Ethernet (PoE) voltage:One of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
57 V
Power over Ethernet (PoE):The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
Power supply:The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable.
50 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
26 W
AC input frequency:
50/60 Hz
AC input voltage:The voltage of the AC electricity that is inpitted into the product.
100 - 240 V
Power source type:What the power source is.
AC, PoE
Protocols
DHCP server:A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one.
Security
MAC address table:The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
2000 entries
Filtering:The type of filtering used.
Security algorithms:Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
WAN connection
3G/4G USB modem compatibility:
Weight & dimensions
Depth:The distance from the front to the back of something.
110 mm
Height:The measurement of the product from head to foot or from base to top.
184.1 mm
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
1.1 kg
Width:The measurement or extent of something from side to side.
110 mm
Wireless LAN features
WLAN data transfer rate (third band):
5700 Mbit/s
WLAN data transfer rate (second band):
4300 Mbit/s
WLAN data transfer rate (first band):
688 Mbit/s
Wi-Fi standards:The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
WLAN data transfer rate (max):
5700 Mbit/s
Top Wi-Fi standard:
Wi-Fi 7 (802.11be)
Wi-Fi band:
Tri-band (2.4 GHz / 5 GHz / 6 GHz)
