Antenna
Antenna gain level (max):Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction.
5 dBi
Antenna connector type:The way in which the antenna is connected to the device e.g. coaxial.
RP-SMA
Antenna type:Type of antenna, also known an aerial, e.g. external, internal.
2x2
Antenna design:
Internal & external
Certificates
Compliance certificates:
CE, Federal Communications Commission (FCC), Industry Canada (IC)
Data transmission
Maximum data transfer rate:
866.7 Mbit/s
Features
LED indicators:
Signal strength, Status
Mounting type:Type of mounting e.g. wall mounting.
Wall
Material:The material from which a thing is or can be made e.g. wood, plastic.
Polycarbonate (PC)
Product type:The sub-category of the product.
Network bridge
Network
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates:The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Ethernet LAN interface type:
Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates:The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Ethernet LAN interface type:
Gigabit Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Operational conditions
Operating relative humidity (H-H):
5 - 95%
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-10 - 40 °C
Packaging content
Power supply included:There is a power supply with this product.
Mounting bracket(s) included:
Packaging data
Quantity per pack:The amount in each pack.
1 pc(s)
Ports & interfaces
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Connectivity technology:
Wired & Wireless
Power
Power over Ethernet (PoE):The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
Power consumption (max):The maximum amount of power used by the device.
25 W
AC input frequency:
50/60 Hz
AC input voltage:The voltage of the AC electricity that is inpitted into the product.
100 - 240 V
Power source type:What the power source is.
AC
Weight & dimensions
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
200 g
Height:The measurement of the product from head to foot or from base to top.
34 mm
Depth:The distance from the front to the back of something.
55 mm
Width:The measurement or extent of something from side to side.
130 mm
Wireless LAN features
Frequency band:A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones.
5 GHz
Top Wi-Fi standard:
Wi-Fi 5 (802.11ac)
Wi-Fi band:
Single-band (5 GHz)
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
