j5create ScreenCast 4K Max Wireless Display Adapter

Quick Code: Q1972667 MPN: JVAW76MAX-N
£88.00

In Stock

Key Features

  • Supports up to 4K UHD video
  • PIN Code Function for Miracast®
  • Wireless transmission distance up to 50 ft. (15m)
  • Customizable background image

Overview



Wirelessly display content from a phone, tablet, or laptop onto a bigger screen with the ScreenCast 4K Max Wireless Display Adapter. Cast to TVs, projectors, and monitors. With its support of multiple wireless display standards (Miracast™, AirPlay®, and Chromecast™), this wireless display adapter is compatible with mobile devices you already own, including Windows®, macOS®, iOS®, Android™ and other cast compatible laptops, tablets, and mobile phones. In addition to its compact design, the ScreenCast 4K Max Wireless Display Adapter features an external antenna for enhanced signal coverage, making it perfect for home use and travel. The JVAW76MAX adds more features for business or education scenarios, such as Point-to-Point mode (use your Windows® device, Mac®, iPad®, or iPhone® without setting up a Wi-Fi® connection). A customizable background image gives you the ability to better express your corporate identity. Includes a Miracast™ pin code feature for additional security.




At-a-glance



  • Built-in dual band (2.4 GHz and 5 GHz) ensures a stable connection

  • Customizable background image

  • Features an Admin Gateway Password for enhanced management security

  • Includes an HDMI™ extension cable for added convenience

  • Native support for AirPlay®, Miracast®, & Chromecast™ (Google Cast™)

  • Native support for Point-to-Point Mode for AirPlay® and Miracast® without setting up a Wi-Fi® connection

  • PIN Code Function for Miracast®

  • Quick and easy setup - No apps or Wi-Fi® needed for Airplay® and Miracast™ devices

  • Supports up to 4K UHDCloseUltra High Definition (UHD) is the resolution 3840x2160 pixels. What this means is that there are more pixels per inch (PPI) in a UHD display than a FHD (Full High Definition 1920x1080) display. This gives a higher resolution display video

  • Wireless transmission distance up to 50 ft. (15m)




Reasons to buy


  • Built-in dual band (2.4 GHz and 5 GHz) ensures a stable connection
  • Customizable background image
  • Features an Admin Gateway Password for enhanced management security
  • Includes an HDMI™ extension cable for added convenience
  • Native support for AirPlay®, Miracast®, & Chromecast™ (Google Cast™)
  • Native support for Point-to-Point Mode for AirPlay® and Miracast® without setting up a Wi-Fi® connection
  • PIN Code Function for Miracast®
  • Quick and easy setup - No apps or Wi-Fi® needed for Airplay® and Miracast™ devices
  • Supports up to 4K UHD video
  • Wireless transmission distance up to 50 ft. (15m)

Specification


Technical Description: j5create ScreenCast 4K Max Wireless Display Adapter

Features
Compatibility:The other products, software and hardware this product can be used with.
Windows® 10 or later, Android™ 8.0 or later, macOS® 10.15 or later with AirPlay® support, iOS® 10.0 or later, iPadOS® 13 or later, Chrome OS™
Mac operating systems supported:Mac operating systems e.g. OS X can be used with the device.
Yes
Windows operating systems supported:Windows vesions wich can be used with the device.
Yes
Product colour:
White
Cable length:How long the cable is.
1 m
Firmware upgradeable:
Yes
Material:The material from which a thing is or can be made e.g. wood, plastic.
Plastic
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.11ac
Plug and Play:Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
Yes
Resolution:The degree of detail in a device.
3840 x 2160 pixels
Security algorithms:Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
WPA2
Supported video modes:The video modes that can be displayed by the device.
720p, 1080p, 2160p
Maximum transfer distance:The greatest distance over which the data/signal can be transferred.
15 m
Maximum resolution:The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
3840 x 2160 pixels
Type:Characteristics of the device.
AV receiver

Logistics data
Master (outer) case GTIN (EAN/UPC):
24712795089459
Products per master (outer) case:
20 pc(s)
Master (outer) case gross weight:
3.5 kg
Master (outer) case height:
190 mm
Master (outer) case length:
435 mm
Master (outer) case width:
230 mm
Export Control Classification Number (ECCN):
EAR99
Minimum order quantity:
20 pc(s)
Products per shipping (inner) case:
5 pc(s)
Shipping (inner) case height:
16.5 cm
Shipping (inner) case length:
21.8 cm
Shipping (inner) case width:
10.3 cm

Operational conditions
Operating relative humidity (H-H):
0 - 85%
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-10 - 40 °C
Storage relative humidity (H-H):
0 - 85%
Storage temperature (T-T):The minimum and maximum temperatures at which the product can be safely stored.
-20 - 50 °C

Packaging content
Packaging content:
1 - JVAW76MAX ScreenCast 4K Max Wireless Display Adapter, 1 - External antenna with USB™ Type-A power cable (39”), 1 - HDMI™ extension cable (5.11”), 1 - Quick Installation Guide (QIG)
Cables included:
USB
AC adapter included:
Yes

Packaging data
Package type:The type of product package e.g. box.
Box
Package weight:Weight of the packaged product.
134 g
Package height:The distance from the top to the bottom of the packaging.
40 mm
Package depth:The distance from the front to the back of the packaging.
95 mm
Package width:The distance from one side of the packaging to the other.
155 mm
Quantity per pack:The amount in each pack.
1 pc(s)

Ports & interfaces
USB version:Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.
2.0
USB ports quantity:
1
HDMI in:Port (socket) for HDMI input.
1
HDMI version:
1.4
WLAN data transfer rate (first band):
200 Mbit/s
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Yes
Connectivity technology:
Wireless

Power
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
1.5 W
Output current:
1 A
Operating voltage:Defines the range of operating voltages available
5 V
Power source type:What the power source is.
USB

Technical details
Country of origin:Country where the device is made.
Taiwan
Warranty period:
2 year(s)

Weight & dimensions
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
79.5 g
Height:The measurement of the product from head to foot or from base to top.
95 mm
Depth:The distance from the front to the back of something.
11 mm
Width:The measurement or extent of something from side to side.
32 mm


Product details


JVAW76MAX-N j5 create

j5create ScreenCast 4K Max Wireless Display Adapter

£88.00 and In stock

SKUJVAW76MAX-N
