Camera
Camera shutter speed:Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
1/1 – 1/10000
White balance:Technique in photography and image processing, which involves a global adjustment of the intensities of the colors (typically red, green, and blue primary colors). An important goal of this adjustment is to render specific colors – particularly neutral colors including white – correctly.
ATW, Auto, Indoor, Manual, One push, Outdoor, Sodium lamp
Pan preset speed:
100 °/sec
Tilt preset speed:
50 °/sec
Tilt angle range:
-30 - 90°
Lens viewing angle, horizontal:
70.2 – 4.1
Minimum illumination:Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
0.4 lx
Design
Mounting type:Type of mounting e.g. wall mounting.
Ceiling/wall
Form factor:The shape or design of the product.
Dome
General
Type:Characteristics of the device.
Security Cameras
Image sensor
Optical sensor size:Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
25.4 / 2.5 mm (1 / 2.5")
Sensor type:A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
CMOS
Lens system
Maximum aperture number:
3.8
Minimum aperture number:The minimum size of the hole through which light enters a camera.
2
Auto focus:Device focusing a camera or other piece of equipment automatically.
Optical zoom:Indicates the optical zoom capacity, which is the number of times that the picture can be enlarged with the optics of the camera.
20x
Zoom capability:The amount that the camera lens can zoom.
Network
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
NDI|HX2, NDI|HX3, RTMP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.3at
Bluetooth:Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
NDI|HX2, NDI|HX3, RTMP
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.3at
Bluetooth:Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Wi-Fi:Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Operational conditions
Operating relative humidity (H-H):
0 - 80%
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-10 - 40 °C
Packaging content
Number of cameras:The quantity of cameras that product can support.
1
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera):
50 dB
Performance
Light exposure modes:The different lengths of time for the exposure for a camera e.g. longer exposure for low light.
Auto, Manual, Shutter priority AE
Connectivity technology:
Wired
Placement supported:Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
Indoor
Type:Characteristics of the device.
IP security camera
Ports & interfaces
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
USB port:Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the cables, connectors and communications protocols used in a bus for connection, communication, and power supply between computers and electronic devices. USB was designed to standardize the connection of computer peripherals (including keyboards, pointing devices, digital cameras, printers, portable media players, disk drives and network adapters) to personal computers, both to communicate and to supply electric power. It has become commonplace on other devices, such as smartphones, PDAs and video game consoles. USB has effectively replaced a variety of earlier interfaces, such as serial and parallel ports, as well as separate power chargers for portable devices.
Microphone in:The socket where a microphone is connected to the device.
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Power
Power consumption (max):The maximum amount of power used by the device.
26.8 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
23.2 W
Power source type:What the power source is.
DC
Video
Back Light Compensation (BLC):
Highlight Compensation (HLC):
Image stabilizer:This camera function compensates for slight shaking movements caused by an unstable position and ensures smooth footage even in suboptimal conditions.
Noise reduction technology:
2D noise reduction, 3D noise reduction
Total megapixels:A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
8.5 MP
Weight & dimensions
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
2.7 kg
Height:The measurement of the product from head to foot or from base to top.
195 mm
Depth:The distance from the front to the back of something.
217 mm
Width:The measurement or extent of something from side to side.
164 mm
